ASUS P8C WS

2-3

Chapter 2

Layout contents

Connectors/Jumpers/Switches/Slots Page

1. LGA1155 CPU Socket 2-4

2. Power connectors (24-pin EATXPWR, 8-pin EATX12V)

2-26

3. DDR3 DIMM slots

2-5

4. CPU, chassis, and power fan connectors (4-pin CPU_FAN,

4-pin CHA_FAN1-3, 3-pin PWR_FAN)

2-22

5. MemOK! switch

2-11

6. USB 3.0 connector (20-1 pin USB3_12)

2-20

7. Intel

C216 Serial ATA 6.0 Gb/s connectors

(7-pin SATA6G_1-2 [gray])

2-17

8. Intel

C216 Serial ATA 3.0 Gb/s connectors

(7-pin SATA3G_3–6 [blue])

2-18

9. Standby Power LED

2-13

10. System panel connector (20-8 pin PANEL)

2-27

11. Clear RTC RAM (3-pin CLRTC)

2-15

12. USB 2.0 connectors

(Type A: 10-1 pin USB1314; Type B: USB11/ USB12)

2-19

13. Parallel port connector (26-1 pin LPT1)

2-20

14. TPM connector (20-1 pin TPM)

2-24

15. Serial port connector (10-1 pin COM1)

2-23

16. Digital audio connector (4-1 pin SPDIF_OUT)

2-21

17. IEEE 1394a port connector (10-1 pin IE1394_2)

2-21

18. GPU Boost Switch

2-10

19. EPU Switch

2-9

20. Chassis Fan control setting (3-pin CHAFAN_SEL)

2-16

21. Front panel audio connector (10-1 pin AAFP)

2-23

Questions and Answers:

Need help?

Do you have a question about the Asus P8C WS and is the answer not in the manual?

Asus P8C WS Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® C216
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Server 2008 R2 Enterprise Windows Server 2008 Enterprise 32/64-bit Windows Server 2003 R2 Enterprise 32/64-bit Windows 7 32/64-bit Windows XP 32/64-bit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16, 2x4, 2x8
PCI Express slots quantity	5
LAN controller	Intel® 82574L
Networking features	2 x Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit
