Asus P8C WS User Manual

x
P8C WS specications summary
CPU LGA1155 socket for Intel
®
2
nd
/ 3
rd
Generation Core™ i3 desktop processor
LGA1155 socket for Intel
®
Xeon
®
E3-1200/ 12x5 v2 series processor
Supports 32nm / 22nm CPU
* Supports Intel
®
Turbo Boost technology 2.0.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
C216 Chipset
Memory 4 x DIMMs, max. 32GB, DDR3 1600 / 1333 MHz, ECC non-ECC, un-buffered
memory
Dual-channel architecture
Supports Intel
®
Extreme Memory Prole (XMP)
**Refer to www.asus.com or this user manual for the Memory QVL (Qualied
Vendors Lidts)
Expansion
slots
1 x PCIe 3.0 x16 (at x16 or x8) (blue)
1 x PCIe 3.0 x16 (at x8) (black)
2 x PCIe 2.0 x16 (at x4) (white)
1 x PCIe 2.0 x1 (at x1)
1 x PCI
VGA
Output
DVI-I port
Supports DVI with max. resolution 1920 x 1200 at 60Hz
Maximum shared memory of 1GB
Multi-GPU
support
Supports ATI
®
Quad-GPU CrossFireX™ Technology
Storage Intel
®
C216 Chipset:
- 2 x SATA 6.0 Gb/s ports(gray)
- 4 x SATA 3.0 Gb/s ports(blue)
- Intel
®
Rapid Storage Technology supports RAID 0, 1, 5, and 10
* Supports on Intel
®
Smart Response Technology, Intel® Rapid Start
Technology, Intel
®
Smart ConnectTechnology
*
** Supports on Intel
®
Core™ processor family with Windows 7 operating
systems.
LAN 2*Intel
®
82574L GbE LAN
- Support teaming function
USB Intel
®
C216 Chipset:
- 4 x USB 3.0 ports (2 ports at mid-board, 2 ports at back panel)
- 10 x USB 2.0 ports (4 ports at mid-board, 6 ports at back panel)
1394 VIA VT6308S controller supports 2 x 1394a port
Audio Realtek
®
ALC892 8-channel High Denition Audio CODEC
- BD audio layer content protection
- Supports Jack-Detection, Multi-streaming and Front Panel Jack-Retasking
- Optical S/PDIF out ports at back I/O
Workstation
Unique
Features
4 PCIe x 16 slots
G.P. Diagnosis Card bundled
Quick Gate: 1 vertical USB 2.0 on board
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI
2.0a, Multi-language BIOS, ASUS EZ Flash Utility, ASUS CrashFree BIOS 3
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
(continued on the next page)

Asus P8C WS Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 2.0 ports quantity	6
Audio chip	Realtek ALC892
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® C216
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows Server 2008 R2 Enterprise Windows Server 2008 Enterprise 32/64-bit Windows Server 2003 R2 Enterprise 32/64-bit Windows 7 32/64-bit Windows XP 32/64-bit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Parallel processing technology support	Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16, 2x4, 2x8
PCI Express slots quantity	5
LAN controller	Intel® 82574L
Networking features	2 x Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	245 mm
Width	305 mm
