3-28
Chapter 3: BIOS setup
Chapter 3
Chassis Fan Speed Low Limit [600 RPM]
This item appears only when you enable the Chassis Q-Fan Control feature and allows you
to disable or set the chassis fan warning speed.
Conguration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
Chassis Fan Profile [Standard]
This item appears only when you enable the Chassis Q-Fan Control feature and
allows you to set the appropriate performance level of the chassis fan.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust depending
on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan operation.
[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set Chassis Fan Prole to [Manual].
Chassis Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The values range
from 40ºC to 90ºC.
Chassis Fan Max. Duty Cycle(%) [100]
Use the <+> and <-> keys to adjust the maximum chassis fan duty cycle. The values range
from 60% to 100%. When the chassis temperature reaches the upper limit, the chassis fan will
operate at the maximum duty cycle.
Chassis Lower Temperature [40]
Displays the lower limit of the chassis temperature.
Chassis Fan Min. Duty Cycle(%) [60]
Use the <+> and <-> keys to adjust the minimum chassis fan duty cycle. The values range from
60% to 100%. When the chassis temperature is under 40ºC, the chassis fan will operate at the
minimum duty cycle.
CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through the onboard
voltage regulators. Select Ignore if you do not want to detect this item.
Anti Surge Support [Enabled]
This item allows you to enable or disable the Anti Surge function.
Conguration options: [Disabled] [Enabled]

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8C WS and is the answer not in the manual?

Asus P8C WS Specifications

General IconGeneral
ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR3-SDRAM
Supported memory clock speeds1333, 1600 MHz
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Maximum number of SMP processors1
Number of SATA III connectors2
Number of Parallel ATA connectors-
USB 2.0 ports quantity6
Audio chipRealtek ALC892
Cooling typePassive
Component forPC
Motherboard chipsetIntel® C216
Audio output channels7.1 channels
Motherboard form factorATX
Compatible operating systemsWindows Server 2008 R2 Enterprise Windows Server 2008 Enterprise 32/64-bit Windows Server 2003 R2 Enterprise 32/64-bit Windows 7 32/64-bit Windows XP 32/64-bit
RAID levels0, 1, 5, 10
Supported storage drive interfacesSATA II, SATA III
Parallel processing technology supportQuad-GPU CrossFireX
PCI Express slots version2.0, 3.0
PCI Express configurations1x16, 2x4, 2x8
PCI Express slots quantity5
LAN controllerIntel® 82574L
Networking features2 x Gigabit LAN
Ethernet interface typeGigabit Ethernet
BIOS typeAMI
ACPI version2.0a
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth245 mm
Width305 mm
