Asus P8H67-M LE User Manual

ASUS P8H67-M 1-7
1.5.3 Motherboard layout
1.5.4 Layout contents
P8H67-M
PCIEX16_1
PCIEX16_2
PCI1
PCIEX1_1
LPT
COM1
USB910USB1112 USB78USB1314
C
LR
T
C
AAFP
EATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
ALC
887-VD
RTL
8111E
EPU
ASM
1442
4MB
BIOS
VIA
VT6415
Asmedia
ASM1083
SB_PWR
SPDIF_OUT
23.4cm(9.2in)
24.5cm(9.6in)
LGA1155
Intel
®
H67
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_A2 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module) DDR3 DIMM_B2 (64bit, 240-pin module)
SATA3G_2SATA3G_1
SATA3G_4SATA3G_3
SATA6G_2SATA6G_1
PRI_EIDE
PANEL
TPM
MemOK!
DRAM_LED
AUDIO
KB_USB56
LAN1_USB12
HDMI
USB34
SPDIF_O2
VGA
2
1 53 4 6
9
8
7
11
10
1
1214 13151617
Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1.
ATX power connectors (24-pin EATXPWR, 8-pin
EATX12V)
1-25 10. Standby Power LED (SB_PWR) 1-31
2. Serial port connectors (10-1 pin COM1)
1-24 11.
Serial ATA connectors (7-pin SATA3G1-4, 7-pin
SATA6G1-2 )
1-23
3. Intel
®
CPU socket 1-8 12. Clear RTC RAM (3-pin CLRTC) 1-20
4.
CPU and Chassis fan connectors (4-pin CPU_FAN,
3-pin CHA_FAN)
1-23 13. System panel connector (20-8 pin PANEL) 1-28
5. DDR3 DIMM sockets 1-13 14.
USB connectors (10-1 pin USB78, USB910,
USB1112, USB1314)
1-26
6. MemOK! switch 1-30 15. LPT connector (26-1 pin LPT ) 1-24
7 DRAM LED 1-31 16. Front panel audio connector (10-1 pin AAFP) 1-22
8. TPM connector (20-1 pin TPM) 1-29 17. Digital audio connector (4-1 pin SPDIF_OUT) 1-26
9. IDE connector (40-1 pin PRI_EIDE) 1-27

Asus P8H67-M LE Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
CPU Socket	LGA 1155
Maximum Memory	32GB
Memory Type	DDR3
PCIe x16 Slots	1
PCIe x1 Slots	2
PCI Slots	1
Audio Chipset	Realtek ALC887
LAN Chipset	Realtek 8111E
Max. LAN Speed	10/100/1000Mbps
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
Memory Standard	DDR3 1333/1066 MHz
SATA 6Gb/s	2
USB 2.0 Ports	10
USB 3.0 Ports	2
Audio Channels	8
Video Ports	DVI, VGA
