19
ASUS STRIX Sound Card Series User Manual
English
4.5.2 Connecting4ChannelSpeakers/PowerAmplier
No. Items Description
1. Front Out Connects to the front input ports of 4.1 speaker.
2. Rear Output Port Connects to the rear surround input port of 4.1
channel speaker.
Amplifier
OR
Side+
S/PDIF Out
Mic/Line-in
Headphone
Front
Box Link
Rear
Center
1
2
