ASUS STRIX Sound Card Series User Manual
English
No. Items Description
1. Front Out Connects to the front input ports of 5.1 speaker.
2. Rear Output Port Connects to the “left surround” and “right surround” input
ports of 5.1 speaker.
3. Center/Subwoofer Connects to the “Center” and “subwoofer” input ports of
5.1 speaker.
4.5.3 Connecting 5.1 Channel Speakers / 5.1 Channel Headphone
Side+
S/PDIF Out
Mic/Line-in
Headphone
Front
Box Link
Rear
Center
1
2
3
