Chapter 2: Hardware Setup
2-8
Dual CPU configuration
A1 B1 C1 D1 E1 F1 G1 H1 J1 K1 L1 M1
2 DIMMs
P
- - - - -
P
- - - - -
4 DIMMs
P P
- - - -
P P
- - - -
6 DIMMs
P P P
- - -
P P P
- - -
8 DIMMs
P P
-
P P
-
P P
-
P P
-
12 DIMMs
P P P P P P P P P P P P
Dual CPU configuration
YoucanrefertothefollowingrecommendedmemorypopulationforadualCPUconguration.
Single CPU configuration
YoucanrefertothefollowingrecommendedmemorypopulationforasingleCPUconguration.
Single CPU configuration (must be installed on CPU1)
A1 B1 C1 D1 E1 F1
1 DIMM
P
- - - - -
2 DIMMs
P P
- - - -
4 DIMMs
P P
-
P P
-
6 DIMMs
P P P P P P
