Back side
ThebacksideoftheSATA/SASbackplanefacestherearpanelwheninstalled.Thisside
includesthepowerconnectorsandSATA/SASinterfacesforthemotherboardSerialATA
connectorsortheSAScard.
BPSMB1
PWR1
MSAS_HD1
Connectors Description
MSAS_HD1
ConnectstoSATASGPIO1connectoronthemotherboardor
connectstoSATA/SASconnectorsontheASUSPIKEIIcard.
BPSMB1
Connects to AUX_PANEL1connectoronthemotherboard
PWR1
Connects to 4-pin plug of the power supply
