ASV RT-30 - General Structure

3.1 General Structure
Key
1. Bucket
2. Lift Arm
3. Operator Enclosure (R.O.P.S./F.O.P.S. approved)
4. Hydraulic Oil (fill location)
5. Diesel Fuel (fill location)
6. Hood (engine cover)
7. Engine
8. Drive Motor and Sprocket
9. Undercarriage
10. Quick Attach
11. Product PIN Plate (beside operator seat, inside enclosure)
3 TECHNICAL DATA
1
2
3
8
6
5
4
7
10
9
31
11
RT-30 US-AUS / R070T US O&M
0404-642 2017-01
