5.3 Starting Procedure
Before starting the engine, perform the pre-operation safety checklist. Once com-
plete, you may proceed by following this procedure:
1. Enter machine with lift arms all the way down. Maintain three points of
contact with the machine (fig. 5.3-1).
2. Sit down into the operator’s seat, fasten seat belt, then lower lap bar into
position.
3. Starting with the throttle in the SLOW (turtle icon) position, push the throttle
1/3 the way open (toward the rabbit icon).
4. Turn the ignition key to the left for 6 seconds to “pre-heat” the engine.
While pre-heating, the glow plug operation light will illuminate.
5. Turn the ignition key to the right to start the engine.
6. With the exhaust adequately vented, bring the engine and hydraulic oil up to
operating temperature. Low oil temperatures can cause the control system
to respond sluggishly.
7. Set the throttle to desired rpm for operation.
Note: The parking brake is automatically engaged when the machine is turned
off.
5 OPERATION
48
5.3-1 5.3-2
Entering or exiting the vehicle under raised lift arms could result in injury
or death. Never allow anyone beneath raised, unsecured lift arms
(fig. 5.3-2).
RT-30 US-AUS / R070T US O&M
0404-642 2017-01
Personal Protective Equipment should be worn during operation in
accordance with section 2 of this manual.
