3.6 Transmission VT-70 High Output
3.7 Auxiliary Hydraulics VT-70 High Output
3.8 Ground pressure VT-70 High Output
3.9 Operating Specs. VT-70 High Output
N
ote: The Maximum Gross Vehicle Weight of the VT-70 High Output is not to
exceed 11,385 lb (5164 kg.). This includes an operator, accessories, attachments
and material being carried.
* Tipping load and operating capacity are measured
using a foundry bucket.
3.10 Refill Capacities (approx.) VT-70 High Output
Drive System Hydrostatic
Type Rexroth A22VG
Design Variable disp./axial piston
Displacement 2.349 in. ³ (38.5 cc) / rev.
Relief Pressure 5500 psi (380 Bar)
Flow 0-22.9 gpm (86.7 lpm)
High Flow 27.9 gpm (105.6 lpm)
Relief pressure 3300 psi (227.5 Bar)
At operating weight 4.6 psi (.317 Bar)
Tipping load 6650 lb (3016 kg)
Operating capacity 50% 3325 lb (1508 kg)
Operating capacity 35% 2328 lb (1056 kg)
Fuel tank 23.2 gal (87.8 l)
Hydraulic tank 4.5 gal (17 l)
Engine coolant 3.5 gal (13.3 l)
Engine oil w/ filter 7 qt (6.6 l)
Planetary Drive .95 qt (.9 l)
33
3 TECHNICAL DATA
VT-70 High Output US ISO O&M
0404-853 2019-09
