Atag CS4411B User Manual

EN 12
CHANGING THE OVEN LAMP
Replacing the oven lamp and cleaning the glass cap
1. Take o the cap by turning counterclockwise.
2. Remove the metal ring and the two sheet rings and
clean the glass cap.
3. If necessary, replace the bulb with a 25 Watt, 230 V,
300 °C heat resistant oven light bulb.
4. Fit the metal and the sheet ring to the glass cap.
5. Reinstall the glass cap.
Bulb
Metal
ring
Sheet
ring
Glass
cap
Sheet
ring

Atag CS4411B Specifications

General

Power Source	230 V ~ 50 Hz
Power Consumption Maximum Power Grill Mode Hot Air Mode Steam Mode	3100 W 2500 W 2400 W 2800 W
Cooling Method	Cooling fan motor

Weight and Dimensions

Dimensions Set size: Built in size:	W 595 x H 454 x D 569.4 mm W 555 x H 445 x D 548.8 mm
Volume	50 liter
Weight Net Shipping	38 kg 41.5 kg
