DESCALE MODE
When you see the message (see the below picture 1) on the display, the machine needs to
be descaled.
1
Pour 500 ml mixed solution of descaler
and clean water in the water tank.
Regarding to mixing ratio, refer to the
user manual of descaler.
2
Close the lid of water tank before
installing into main unit.
3
Turn the FUNCTION KNOB to “OFF”
position.
4
Close the door and press and
hold down both END TIME and
WEIGHT/TEMP for 3 seconds.
The machine displays 50 minutes
and starts descaling.
 Cleaning Mode: 40 min
 Rinse Mode: 10 min

Atag CS4411B Specifications

General

Power Source	230 V ~ 50 Hz
Power Consumption Maximum Power Grill Mode Hot Air Mode Steam Mode	3100 W 2500 W 2400 W 2800 W
Cooling Method	Cooling fan motor

Weight and Dimensions

Dimensions Set size: Built in size:	W 595 x H 454 x D 569.4 mm W 555 x H 445 x D 548.8 mm
Volume	50 liter
Weight Net Shipping	38 kg 41.5 kg
