Atag i28C Installation & Servicing Instructions

Installation & Servicing instructions ATAG iC-Range
59
From
previous
page
VERIFY FLUE INTEGRITY
Analyser readings indicate that combustion products and inlet air
must be mixing. Further investigation of the ue is therefore required.
Check that ue components are assembled, xed and supported as
per boiler/ue manufacturer’s instructions.
Check that ue and ue terminal are not obstructed.
Is
O
2
> 20.6%
and
CO
2
< 0.2%
Is
O
2
> 20.6%
and
CO
2
< 0.2%
CHECK CO AND COMBUSTION RATIO AT MAX. RATE
With boiler still set at maximum gas rate, insert analyser probe into
ue gas sampling point.
Allow readings to stabilise before recording.
TURN OFF APPLIANCE AND CALL
ATAG TECHNICAL HELPLINE FOR
ADVICE. 0800 254 5065
THE APPLIANCE MUST NOT BE
COMMISSIONED UNTIL PROBLEMS ARE
IDENTIFIED AND RESOLVED.
Is
CO less than
350ppm and
CO/CO
2
ratio less
than 0.0040
YES
NO
Check all seals around the appliance burner,
internal ue seals, door and case seals.
Rectify where necessary.
SET BOILER TO MINIMUM RATE
In accordance with boiler instructions, set boiler to operate at
minimum rate (to minimum load condition). Allow su󰀩cient time for
combustion to stabilise.
CHECK CO AND COMBUSTION RATIO AT MINIMUM RATE
With boiler still set at minimum rate, insert analyser probe into ue
gas sampling point. Allow readings to stabilise before recording.
Is
CO less than
350ppm and
CO/CO
2
ratio less
than 0.0040
BOILER IS OPERATING SATISFACTORILY
No further actions required.
Ensure test points are capped, boiler case is correctly ret and all
other commissioning procedures are completed.
Complete Benchmark Checklist, recording CO and combustion ratio
readings as required.
Is
CO less than
350ppm and
CO/CO
2
ratio less
than 0.0040
TURN OFF APPLIANCE AND CALL
MANUFACTURER’S TECHNICAL HELPLINE
FOR ADVICE.
THE APPLIANCE MUST NOT BE
COMMISSIONED UNTIL PROBLEMS ARE
IDENTIFIED AND RESOLVED. IF
COMMISSIONING CANNOT BE FULLY
COMPLETED, THE APPLIANCE MUST BE
DISCONNECTED FROM THE GAS SUPPLY IN
ACCORDANCE WITH THE GS(I&U)R.
NOTE: Check and record CO and combustion
ratio at both max. and min. rate before contacting
the manufacturer.
< = less than or
equal to
> = greater than or
equal to
YES
NO
YES
NO
NO
YES
NO
YES
