The ATAG ONE
Zone
is impacted by room temperature so care must be taken to position it away from
anything that is likely to give a misrepresentative reading about the room temperature, such as
from heat sources, draughts, windows and doorways.
It should be installed approximately 1.5 metres
above the floor level.
Installation
Positioning
WARNING! Installation should be
performed by a qualified technician.
!
Securing the ATAG ONE
Zone
Before making any connections, use the
external double-pole switch to shut o
electrical power to the boiler.
See diagram on page opposite (page 9).
Secure the ATAG ONE
Zone
base plate
(A) to the wall and connect the pair
of wires to the terminal clamp to
hook the boiler up via the BUS.
A
Fit the battery in its compartment (B).
B
Reattach the ATAG ONE
Zone
to its
base plate (C) by pushing it
carefully downwards.
C
Alternatively call our support team on 0800 680 0100
Visit: www.atagheating.co.uk/zone
8
