Installation & Servicing Instructions ATAG Q-Series
9
6 Connecting the boiler
The boiler has the following connection pipes;
- The central heating pipes.
These can be connected to the installation by means of compression ttings;
- The gas pipe.
It is provided with a female thread into which the tail piece of the supplied gas isolation
valve can be screwed;
- The condensation drain pipe.
It consists of an oval 24 mm plastic pipe. The drain pipe can be connected to this by
means of an open connection. If the open connection is tted in a different location,
then the pipe can be lengthened by means of a 32 mm PVC sleeve;
- The ue gas exhaust system and air supply system.
It consists of a concentric connection 80/125 mm. The Q51S and Q60S are supplied
with this feature for converting from the standard 2x 80 mm to concentric 80/125 mm.
- Cold and hot water pipes.
Only Combi boilers: These consist of 15 mm copper pipe and can be connected to
the installation by means of compression ttings.
It is recommended that isolation valves are tted to all heating and hot water
connections to facilitate ease of future maintenance.
It is advisable to spray-clean all of the unit’s connecting pipes and/or to spray-
clean/blow-clean the installation before connecting it to the unit.
6.1 Central heating system
Connect the central heating system according to the actual regulations.
The boiler pipes can be connected to the installation by means of compression ttings.
Reducers should be used for connecting to thick-walled pipe (welded or threaded).
When removing the plastic sealing caps from the pipes, contaminated testing
water may be released.
The boiler has a self-adjusting and self-protecting control system for the load and the pump
capacity. This means the temperature difference between the ow and return water is
checked. Table 6.1.a shows the water displacement which supplies the circulation pump
at certain installation resistance.
A low velocity header must be connected to the Q51C, Q51S and Q60S to
prevent ow problems over the boiler.
ATAG supplies the AA1OV09U Low velocity header for 1 boiler. This can be connected
directly under the boiler on the ow and return pipe.
Boiler type Pump type
UPM2 l/min l/h kPa mbar
Q25C 20-70 15,8 950 25 250
Q38C 20-70 24,0 1440 20 200
Q51C 20-70
Q25S 20-70 15,8 950 25 250
Q38S 20-70 24,0 1440 20 200
Q51S 20-70
Q60S 20-70
Low velocity header required
Low velocity header required
Solo
Water flow rate
Permissible installation
restistance
Combi
Low velocity header required
Installation resistance table 6.1.a
