8. Voltage of IC and transistor
N101 LC8632xxx(color bars)
PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Voltage V 0 0 0 5 / 0/5 / / 0 2 2.5 5 5 5
PIN 15 16 17 18 19 20 21 22 23 24 25 26 27 28
Voltage V 2.5 0 5 2.6 3 4.8 4.4 0 0 0 0 / 4.7 4.7
PIN 29 30 31 32 33 34 35 36 37 38 39 40 41 42
Voltage V / / 0 0 0.4 4.8 / / / 0 0 / / 5
N101 LC8632xxx(no signals, blue background)
PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Voltage V 0 0 0 5 / 0 / / 0 1.7 2.5 5 5 5
PIN 15 16 17 18 19 20 21 22 23 24 25 26 27 28
Voltage V 4.6 0 5 2.6 2.5 4.8 4.2 0 0 3.6 3.6 / 4.2 4.2
PIN 29 30 31 32 33 34 35 36 37 38 39 40 41 42
Voltage V / / 0 0 0.4 4.8 / / / 0 0 / / 5
N201 LA76814(no signals, blue background)
PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Voltage V 2.3 2.3 2.5 1.9 2.9 2.9 0 5 2 2.3 4.7 4.7 4 0.8
PIN 15 16 17 18 19 20 21 22 23 24 25 26 27 28
Voltage V 0.8 1.1 0 8 2 2 2 0.4 2.2 2.7 5 2.6 0.7 1
PIN 29 30 31 32 33 34 35 36 37 38 39 40 41 42
Voltage V 1.6 0 0 2.7 0 2.6 2.1 3.9 2.4 2.9 3.6 2.5 0 2.6
PIN 43 44 45 46 47 48 49 50 51 52 53 54
Voltage V 5 2.8 1.9 2.2 3.6 4 4 2.4 2.2 1.9 3.1 2.4
N201 LA76814(no signals, blue background)
PIN 1 2 3 4 5 6 7 8 9 10 11 12 13 14
Voltage V 2.3 2.3 0 5 2.9 2.9 0 5 2 4.6 4.3 4.3 3.7 1.1
PIN 15 16 17 18 19 20 21 22 23 24 25 26 27 28
Voltage V 1.1 3 1.8 7.6 1.2 1.2 2.6 0.2 2.4 2.6 5 2.6 0.7 1
PIN 29 30 31 32 33 34 35 36 37 38 39 40 41 42
Voltage V 1.6 0 0 2.7 0 0 1.3 3.4 0.3 2.9 2.3 2.5 0 2.6
PIN 43 44 45 46 47 48 49 50 51 52 53 54
Voltage V 5 2.8 1.9 3.4 2.9 4 4 2.4 2.2 1.9 3.1 2.4
N304 TDA7056(no signals, blue background)
PIN 1 2 3 4 5 6 7 8 9
Voltage V / 14 2.4 0 0
•
1.1 7 0 7 /
