— 40 —
Non-standard resistor
R
•
•
X
•
•
•
•
•
•
•
•
•
1 2 3 4 5 6 7 8 9 10 11 12
13
Non-standard Capacitor
C
•
•
X
•
•
•
•
•
•
•
•
•
1 2 3 4 5 6 7 8 9 10 11 12
13
5
t
,6
t
,7
t
digits:
Resistance value
2
nd
digit: Category
C Temperature
compensated ceramic
dielectric
G Metallized polyester film
K High dielectric ceramic
dielectric
N Polypropylene film
B Semiconductor ceramic
dielectric
M Metallized Polypropylene
film
J Monolithic H Compound film
E Aluminum-electrolytic T Tantalum-electrolytic
F Polyester film (existed
inductance)
P Non-polarity electrolytic
D Polyester film (no
inductance)
V Variable capacitor
10
,11
digits: Serial no.
01~79(bare copper
wire::80~99)
2
nd
digit: Material
D Carbon film resistor
F Fusible resistor
S Metal oxide film
resistor
C Solid resistor
W Wire resistor
J Metal film resistor
Z Bare copper wire
3
rd
digit: Power
A 1/8W G 3W N 10W
B 1/6W H 5W
C 1/4W J 6W
D 1/2W K 7W
E 1W L 8W
F 2W M 9W — Non
3
rd
digit: Voltage
A 6.3V K 250V
B 10V L 300V
C 16V M 400V
D 25V N AC250V
E 35V R 630V
F 50V Z 1.6KV
G 100V X 2KV
H 160V Y 63V
J 200V
9
th
digit: Distance of
lead (mm)
0 —
1 5.0
2 7.5
3 10
4 12.5
5 15
6 17.5
7 20
8 22.5
9 25
A 27.5
B 30
8
th
digit: Error
A
+
0.05%
B
+
0.1%
C
+
0.25%
D
+
0.5%
F
+
1%
G
+
2%
J
+
5%
LK
+
10%
M
+
20%
N
+
30%
P
+100%,-0%
Z
+80%,-20%
—
Non
5
th
,6
th
,7
th
digits: Capacitance value
2
nd
digit 5
th
,6
th
digit 7
th
,8
th
digit
V Minimum Maximum
8
th
digit: Error
A +
0.05%
J +
5%
B +
0.1%
K +
10%
C +
0.25%
M +
20%
D +
0.5%
P +100-0%
F +
1%
Z +80-20%
G +
2%
12
th
digit: Type
N Bulk
T 52
R 26
Axial pop-up
box
B 52
C 26
Axial disk
form
E
F
G
Flake disk form
Radial pop-up box
Radial disk form
12
th
digit: Type
N Bulk
T 52mm
R 26mm
Axial
pop-up
box
B 52mm
C 26mm
Axial disk
form
E Flake disk form
F Radial pop-up box
G Radial disk form
9
th
digit: Distance of
lead (mm)
0 —
1 5
2 7.5
3 10
4 12.5
5 15
6 17.5
7 20
8 22.5
9 25
A 27.5
B 30
C 35
Y 2.5
13
t
digit:
Manufacturer
13
th
digit:
Manufacturer
10
th
,11
th
digits:
Serial no. 01~99
