ATEC-PANDA 2188 - 9. Resistance to Earth of Some Circuits

— 32 —
9. Resistance to Earth of Some Circuits
(With multimeter 500 type×1K/red test pen connected to earth)
N101
•
LC8632XXX
•
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
1
/ 12 3.6K 23 1.6K 34 5K
2 / 13 18K 24 1.6K 35 /
3 / 14 18K 25 1.6K 36 /
4 10K 15 1.5K 26 / 37 /
5 / 16 3.6K 27 2.6K 38 10K
6 10K 17 10K 28 2.6K 39 10K
7 / 18 6K 29 / 40 /
8 / 19 10K 30 / 41 /
9 0 20 18K 31 0 42 10K
10 10K 21 10K 32 0
11 10K 22 1.6K 33 3K
N102
•
AT24C04
•
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
1 0 3
0
5 3K 7 0
2 0 4 0 6 3K 8 3.6K
N201
•
LA76814
•
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
1
1.4K 15 1.7K 29 1.2K 43 0.8K
2 1.4K 16 1.7K 30 2K 44 1.5K
3 1.5K 17 0.9K 31 / 45 1.2K
4 10K 18 1K 32 0.8K 46 0.8K
5 1.2K 19 1.7K 33 0 47 1.7K
6 1.2K 20 1.6K 34 0 48 1.4K
7 0 21 1.6K 35 1.4K 49 1.4K
8 0.8K 22 1.6K 36 1.2K 50 1.5K
9 1.7K 23 1.2K 37 0.9K 51 1.5K
10 1.5K 24 1.3K 38 1.3K 52 1.5K
11 3K 25 1.3K 39 1.5K 53 1.5K
12 3K 26 1.7K 40 1.4K 54 1.5K
13 1.3K 27 1.1K 41 0
14 1.7K 28 1.5K 42 1.5K
