— 33 —
N304
•
TDA7056B
•
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN Resistance
Va lu e
PIN Resistance
Va lu e
1 / 3 100K 5 10K 7 0
2 10K 4 0 6 10K 8 10K
9 /
N401
•
LA7840
•
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN Resistance
Va lu e
PIN Resistance
Va lu e
1 0 3 0.67K 5 0.95K 7 0.8K
2 0.6K 4 0.9K 6 0.5K
N601
•
MC44608P75
•
PIN
Resistance
Va lu e
PIN
Resistance
Va lu e
PIN Resistance
Va lu e
PIN Resistance
Va lu e
1 90K 3 4.4K 5 1K 7 /
2 3.4K 4 0 6 36K* 8 95K*
*1. To measure with multimeter 500 type, the multiplying factor is [
×
10K], and the red test pen
connected to earth.
The resistance to earth of load of each power supply (with multimeter 500 type×1K/red test pen
connected to earth) are as follows:
VD621- =480Ω VD622- =500Ω VD623- =480Ω
VD624- =460Ω VD621- =480Ω
2. When the resistance of N601/PIN6 less than normal value, TV is in status of standby.
When the resistance of N601/PIN8 more than normal value, the switching power supply of TV
is in status of stop.
