CS1732A / CS1734A User Manual
6
No. Component Description
1 Port Selection
Pushbuttons
Pressing a front panel port selection pushbutton brings the
focus to the computer attached to its corresponding port.
 Press a pushbutton for longer than two seconds to bring
complete focus (KVM, Audio, and USB simultaneously)
to the computer attached to its corresponding port.
 Press and release a pushbutton to bring only the KVM
focus to the computer attached to its corresponding port.
 Press pushbuttons 1 and 2 simultaneously for 2 sec-
onds to start Auto Scan Mode.
 Press pushbuttons 3 and 4 simultaneously for 2 sec-
onds to perform a keyboard and mouse reset.
(CS1734
A only)
2 Port LEDs The Port LEDs are built into the Port Selection
Pushbuttons. The upper ones are the KVM Port LEDs; the
lower ones are the USB LEDs:
KVM:
 Lights DIM ORANGE to indicate that the
computer attached to its corresponding port is
up and running (On Line).
 Changes to BRIGHT ORANGE to indicate that
the computer attached to its corresponding port
is the one that has the KVM focus (Selected).
 Flashes to indicate that the computer attached
to its corresponding port is being accessed
under Auto Scan mode.
USB:
 Lights DIM GREEN to indicate that there is a
USB cable connection to the computer attached
to its corresponding port. Does not light if there
is no USB connection to the computer.
 Changes to BRIGHT GREEN to indicate that
the computer attached to its corresponding port
is the one that has access to the USB
peripherals.
3 Console USB
Ports
The cables from your console USB keyboard and USB
mouse plug in here. Each connector is marked with an
appropriate icon to indicate itself.
