Page #25 background imageLoading...
Page #25 background image
Chapter 4. Hotkey Operation
17
Hotkey Setting Mode
Hotkey Setting Mode is used to set up your CS82U / CS84U switch
configuration. All operations begin with invoking Hotkey Setting Mode
(HSM).
Invoking HSM
To invoke HSM do the following:
1. Press and hold down [Num Lock].
2. Press and release [-].
3. Release [Num Lock].
Note: 1. There is an alternate key combination to invoke HSM. See page 18
for details.
2. The minus key must be released within one half second, otherwise
Hotkey invocation is canceled.
When HSM is active, the Caps Lock, and Scroll Lock LEDs flash in succession
to indicate that HSM is in effect. They stop flashing and revert to normal status
when you exit HSM.
Ordinary keyboard and mouse functions are suspended – only Hotkey
compliant keystrokes and mouse clicks (described in the sections that follow),
can be input.
At the conclusion of some hotkey operations, you automatically exit hotkey
mode. With some operations, you must exit manually. To exit HSM manually,
press the Esc key, or the Spacebar.
cs82u-cs84u.book Page 17 Monday, February 6, 2012 4:31 PM

Other manuals for ATEN CS82U

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ATEN CS82U and is the answer not in the manual?

ATEN CS82U Specifications

General IconGeneral
DC-in jackYes
Console portsPS/2, USB A, VGA (D-Sub)
USB connector typeUSB Type-A
Number of computers controlled2
Built-in displayNo
Product colorBlack, Light grey
Housing materialMetal
HD typeQXGA
Scan interval3, 5, 10, 20 s
Video bandwidth60 Hz
Maximum resolution2048 x 1536 pixels
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)0 - 80 %
Power sourceDC
Power consumption (typical)1.1 W
I/O ports2x SPHD-18
Weight and Dimensions IconWeight and Dimensions
Depth140 mm
Width88 mm
Height55.5 mm
Weight540 g
