Chapter 4. OSD Operation
35
SET
KEYBOARD
LANGUAGE
Sets the keyboard language layout for the computers attached to each
port. Press [Spacebar] to cycle through the choices: The default is
English (US).
FIRMWARE
UPGRADE
In order to upgrade the KH1508A / KH1516A / KH1532A and adapter
cable firmware (see The Firmware Upgrade Utility, page 53) you must
first enable Firmware Upgrade mode with this setting.
When you bring up this menu, the current firmware version levels
display. Select Y to enable Firmware Upgrade mode, or N to leave this
menu without enabling it.
ADAPTER
UPGRADE
This function allows the administrator to check the firmware version of
the KVM adapter cable. When you bring up this menu, the current
firmware version levels display. See FIRMWARE UPGRADE, above,
also.
SET LOGIN
MODE
This function allows the administrator to request users to login or not.
When the login dialog box is disabled, the system disables the login/
logout function. If the system is re-started, the login/logout function
remains disabled.
SET VIDEO
HV MODE
This setting selects the video mode (separate or composite video sync
signals) the port(s) (internal/external) is using. Press [Enter] to enter
this setting and see a list of ports. In the list, the “Mode” column will
display the video mode choices, these are:
S Separate (default)
C Composite
Use the [Spacebar] to cycle through the choices. Changes will not
be saved until you exit to the main menu.
Note: Some old adapters may not support HV mode and the “Mode”
column will be empty.
Setting Function
