ATEQ D6 Series User Manual

27 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
RX/RY = 8 words – Commands & Status
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
0
2
00(h)
Command echo:
Command:
X000(h)
Echo reset
Y000(h)
Reset (stop current cycle)
X001(h)
Echo start
Y001(h)
Start (starting a test cycle)
X002(h)
Echo start special cycle
Y002(h)
Start special cycle
X003(h)
Echo program selection
Y003(h)
Program selection
X004(h)
Echo read FIFO results
Y004(h)
Read FIFO results
X005(h)
RESERVED
Y005(h)
RESERVED
X006(h)
RESERVED
Y006(h)
RESERVED
X007(h)
Echo reset FIFO results
Y007(h)
Reset FIFO results
X008(h)
RESERVED
Y008(h)
RESERVED
…
…
X00E(h)
Y00E(h)
X00F(h)
Echo read Last results
Y00F(h)
Read Last results
2
2
01(h)
Command error code:
X010(h)
Error reset
Y010(h)
RESERVED
X011(h)
Error start
…
X012(h)
Error start special cycle
X013(h)
Error program selection
X014(h)
Error read FIFO results
X015(h)
RESERVED
X016(h)
RESERVED
X017(h)
Error reset FIFO results
X018(h)
RESERVED
…
X01E(h)
X01F(h)
Error read Last results
Y01F(h)
4
2
02(h)
X020(h)
Refresh counter
Y020(h)
RESERVED
…
…
X02F(h)
Y02F(h)
6
2
03(h)
X030(h)
Number of current program
Y030(h)
Number of program to be
selected
…
…
X03F(h)
Y03F(h)
8
2
04(h)
X040(h)
Number of FIFO results
Y040(h)
Special cycle code
…
…
X04F(h)
Y04F(h)
10
2
05(h)
X050(h)
Test type
Y050(h)
RESERVED
…
…
X05F(h)
Y05F(h)
