ATEQ D6 Series User Manual

FG_D6_CCLINK_EN_02 / 2020-06-17
50 / 93
CONFIGURATION
General configuration
Table of configuration / extended menu bits
Reminder: “h” indicates a hexadecimal code, “(d)” indicates a decimal code.
The bits below are mostly present in the CONFIGURATION or More functions... menus.
They are only used to allow the access to other parameters according to the configuration, depending
on the configuration, these are active or not.
Acronyms used in the “Menu” column:
— Conf: CONFIGURATION
— +Func: FUNCTIONS > More functions…
— RS232: CONFIGURATION > RS232
Word
Bit n°
Mask
Meaning
*ERD Only
Menu
Hexa
Dec
1
0
0001
1
Fill type.
+Funct
1
0002
2
Recovery thresholds.
+Funct
2
0004
4
End of cycle.
+Funct
3
0008
8
Mini valve.
+Funct
4
0010
16
Peak hold.
+Funct
5
0020
32
ATR1.
+Funct
6
0040
64
ATR2.
+Funct
7
0080
128
Personalization of the program name.
+Funct
8
0100
256
Sequence.
+Funct
9
0200
512
Automatic connector.
+Funct
10
0400
1024
Valves codes (outputs codes).
+Funct
11
0800
2048
Offset.
+Funct
12
1000
4096
Filtering.
+Funct
13
2000
8192
Automatic mode.
+Funct
14
4000
16384
Stamping.
+Funct
15
8000
32768
Reserved.
