Configu
rati
on of the
master
For the master configu
ration,
you
will
use
the
“MELSEC CC
-
Link
Ver.2 utility”
softw
are and a MELSEC
master boa
rd put i
n your com
puter.
CONFIGURE THE MELSEC BOARD AS MASTER
Open
MELS
EC CC-Li
nk Ver.2 utility
softwa
re and
go into the
Parameter set
ting
tab
14
