ATEQ D6 Series User Manual

51 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
Word
Bit n°
Mask
Meaning
*ERD Only
Menu
Hexa
Dec
2
16
0001
1
N test.
+Funct
17
0002
2
Unit type.
+Funct
18
0004
4
Pressure correction.
+Funct
19
0008
8
Reserved.
20
0010
16
Piezo auto zero.
21
0020
32
Reserved.
22
0040
64
Sending condition: pass part.
RS232
23
0080
128
Sending condition: fail part maximum
flow.
RS232
24
0100
256
Sending condition: fail part minimum
flow.
RS232
25
0200
512
Sending condition: presence of an
alarm.
RS232
26
0400
1024
Sending condition: pressure defect.
RS232
27
0800
2048
Sending condition: end of cycle.
RS232
28
1000
4096
Sending condition: recoverable.
RS232
29
2000
8192
Content of the frame: time.
RS232
30
4000
16384
Content of the frame: personalization.
RS232
31
8000
32768
Content of the frame: pressure.
RS232
3
32
0001
1
Security.
Conf
33
0002
2
Exportation.
RS232
34
0004
4
Automatic piezo reset.
35
0008
8
Placing in stand-by.
Main
36
0010
16
Return to operation from stand-by.
Main
37
0020
32
Unused.
38
0040
64
Bar graph displaying.
Conf
39
0080
128
Presence of a second piezo sensor.
40
0100
256
Reserved.
41
0200
512
Reserved.
42
0400
1024
Reserved.
43
0800
2048
Reserved.
44
1000
4096
Reserved.
45
2000
8192
Reserved.
Word
Bit n°
Mask
Meaning
*ERD Only
Menu
Hexa
Dec
4
48
0001
1
Reserved.
49
0002
2
Reserved.
50
0004
4
Sequence.
51
0008
8
Bar code.
52
0010
16
Program selection bar code.
53
0020
32
Single calibration.
+Funct
54
0040
64
No negative.
+Funct
55
0080
128
Reserved.
Conf
56
0100
256
Reserved.
RS232
57
0200
512
Rest mode, blow on test side or
reference side.
Conf
58
0400
1024
Remote control activation.
59
0800
2048
Auxiliary codes activation.
60
1000
4096
Gas option (not available).
61
2000
8192
Pre Fill activation.
62
4000
16384
Sign change activation.
63
8000
32768
Display mode activation.
5
64
0001
1
Flow regulation activation.
65
0002
2
Bar code reset on end of cycle.
66
0004
4
Reserved.
67
0008
8
Reserved.
68
0010
16
Reserved.
69
0020
32
Reserved.
70
0040
64
Reserved.
71
0080
128
Reserved.
72
0100
256
Reserved.
73
0200
512
Reserved.
74
0400
1024
Reserved.
75
0800
2048
Reserved.
76
1000
4096
Reserved.
77
2000
8192
Reserved.
78
4000
16384
Reserved.
79
8000
32768
Page feed.
Word
Bit n°
Mask
Meaning
*ERD Only
Menu
Hexa
Dec
2
16
0001
1
N test.
+Funct
17
0002
2
Unit type.
+Funct
18
0004
4
Pressure correction.
+Funct
19
0008
8
Reserved.
20
0010
16
Piezo auto zero.
21
0020
32
Reserved.
22
0040
64
Sending condition: pass part.
RS232
23
0080
128
Sending condition: fail part maximum
flow.
RS232
24
0100
256
Sending condition: fail part minimum
flow.
RS232
25
0200
512
Sending condition: presence of an
alarm.
RS232
26
0400
1024
Sending condition: pressure defect.
RS232
27
0800
2048
Sending condition: end of cycle.
RS232
28
1000
4096
Sending condition: recoverable.
RS232
29
2000
8192
Content of the frame: time.
RS232
30
4000
16384
Content of the frame: personalization.
RS232
31
8000
32768
Content of the frame: pressure.
RS232
3
32
0001
1
Security.
Conf
33
0002
2
Exportation.
RS232
34
0004
4
Automatic piezo reset.
35
0008
8
Placing in stand-by.
Main
36
0010
16
Return to operation from stand-by.
Main
37
0020
32
Unused.
38
0040
64
Bar graph displaying.
Conf
39
0080
128
Presence of a second piezo sensor.
40
0100
256
Reserved.
41
0200
512
Reserved.
42
0400
1024
Reserved.
43
0800
2048
Reserved.
44
1000
4096
Reserved.
45
2000
8192
Reserved.
46
4000
16384
Reserved.
47
8000
32768
Reserved.
