ATEQ D6 Series User Manual

29 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
WRr/WRw = 32 words – Real time measurements & FIFO / Last results
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
16
4
08(h)
Pressure value (32 bits integer)
Example: Pressure value = 207
On network : 98 28 03 00
00032898(H) → 207000(d)/1000 → 207
WRr00(h)
Low word (LSW)
WRw00(h)
RESERVED
WRr01(h)
High word (MSW)
WRw01(h)
RESERVED
20
4
0A(h)
Pressure unit (32 bits integer)
Example: Pressure unit Pa = 6
On network: 70 17 00 00
00001770(H) → 6000(d)/1000 → 6
WRr02(h)
Low word (LSW)
WRw02(h)
RESERVED
WRr03(h)
High word (MSW)
WRw03(h)
RESERVED
24
4
0C(h)
Flow value (32 bits integer)
Example: Flow value = -0.108
On network: 94 FF FF FF
FFFFFF94(H) → -108(d)/1000 → -0.108
WRr04(h)
Low word (LSW)
WRw04(h)
RESERVED
WRr05(h)
High word (MSW)
WRw05(h)
RESERVED
28
4
0E(h)
Flow unit (32 bits integer)
Example: Flow Unit Pa/s = 8
On network: 40 1F 00 00
00001F40(H) → 8000(d)/1000 → 8
WRr06(h)
Low word (LSW)
WRw06(h)
RESERVED
WRr07(h)
High word (MSW)
WRw07(h)
RESERVED
FIFO / Last results
32
36
10(h)
WRr08(h)
FIFO / Last results
WRw08(h)
RESERVED
…
…
WRr19(h)
WRw19(h)
68
6
22(h)
WRr1A(h)
RESERVED
WRw1A(h)
RESERVED
…
…
WRr1F(h)
WRw1F(h)
