ATEQ D6 Series User Manual

FG_D6_CCLINK_EN_02 / 2020-06-17
32 / 93
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
12
2
06(h)
Relay status:
X060(h)
Pass part (OK)
Y060(h)
RESERVED
X061(h)
Fail test part (NOK)
…
X062(h)
Fail reference part (NOK)
X063(h)
Alarm
X064(h)
Pressure error
X065(h)
Cycle end (system ready)
X066(h)
Part recoverable
X067(h)
Calibration error
X068(h)
Not used
X069(h)
ATR fault
X06A(h)
Not used, always at 0
…
X06F(h)
Y06F(h)
14
2
07(h)
X070(h)
Step
Y070(h)
RESERVED
…
…
X07F(h)
Y07F(h)
