ATEQ D6 Series User Manual

47 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
92
20
2E(h)
Function bits reading:
Function bits writing:
X2E0(h)
Function bits - word 0
Y2E0(h)
Function bits - word 0
…
…
X2EF(h)
Y2EF(h)
X2F0(h)
Function bits - word 1
Y2F0(h)
Function bits - word 1
…
…
X2FF(h)
Y2FF(h)
X300(h)
Function bits - word 2
Y300(h)
Function bits - word 2
…
…
X30F(h)
Y30F(h)
X310(h)
Function bits - word 3
Y310(h)
Function bits - word 3
…
…
X31F(h)
Y31F(h)
X320(h)
Function bits - word 4
Y320(h)
Function bits - word 4
…
…
X32F(h)
Y32F(h)
X330(h)
Function bits - word 5
Y330(h)
Function bits - word 5
…
…
X33F(h)
Y33F(h)
X340(h)
Function bits - word 6
Y340(h)
Function bits - word 6
…
…
X34F(h)
Y34F(h)
X350(h)
Function bits - word 7
Y350(h)
Function bits - word 7
…
…
X35F(h)
Y35F(h)
X360(h)
Function bits - word 8
Y360(h)
Function bits - word 8
…
…
X36F(h)
Y36F(h)
X370(h)
Function bits - word 9
Y370(h)
Function bits - word 9
…
…
X37F(h)
Y37F(h)
WRr/WRw = 96 words – Parameters handling, Program name & FIFO / Last results
Offset
(byte)
Length
(byte)
Offset
(word)
Read table
(MASTER ← ATEQ)
Write table
(MASTER → ATEQ)
112
128
38(h)
WRr00(h)
Parameters reading
WRw00(h)
Parameters writing
…
…
WRr39(h)
WRw39(h)
240
16
78(h)
WRr40(h)
Program name reading
WRw40(h)
Program name writing
…
…
WRr47(h)
WRw47(h)
256
80
80(h)
WRr48(h)
FIFO / Last results
WRw48(h)
RESERVED
…
…
WRr6F(h)
WRw6F(h)
336
12
A8(h)
WRr70(h)
RESERVED
WRw70(h)
RESERVED
…
…
WRr7F(h)
WRw7F(h)
