53 / 93
FG_D6_CCLINK_EN_02 / 2020-06-17
Example: bit number 13 (automatic mode) activated to 1, will place to "2000h" the value in the first
word.
2000h is equivalent to 8192 in decimal and 0010000000000000 in binary.
In the Modbus frame, the words will follow each other: word 1 + word 2 + ….. + word n.
Word
Bit n°
Mask
Meaning
*ERD Only
Menu
Hexa
Dec
6
80
0001
1
Service cycles activation.
81
0002
2
Buzzer.
82
0004
4
Sequences activation.
83
0008
8
Reserved.
84
0010
16
Standard conditions.
85
0020
32
Bar graph display.
86
0040
64
Up Contact *
+Funct
87
0080
128
Down Contact *
+Funct
88
0100
256
Pressure Up *
+Funct
89
0200
512
Pressure Down *
+Funct
90
0400
1024
Step Flow *
+Funct
91
0800
2048
Start Press *
+Funct
92
1000
4096
Short Cycle *
+Funct
93
2000
8192
Sending condition: Fail up ERD *
RS232
94
4000
16384
Sending condition: Fail step ERD *
RS232
95
8000
32768
Sending condition: Fail down ERD *
RS232
7
96
0001
1
Regulation mode.
+Funct
97
0002
2
Analog output.
+Funct
98
0004
4
Measure delay *
+Funct
