Step table
This table
represents
the codes of
the steps
in the cy
cle.
Code
Steps
*ERD Only
Decimal
Hexadeci
mal
0
0
0
00
Pre-fill.
1
0
0
01
Fill
2
0
0
02
Zero Diff.
3
0
0
03
Stabilizati
on
4
0
0
04
Test
5
0
0
05
Dump
7
0
0
07
Up*
8
0
0
08
Step*
9
0
0
09
Down*
6
5
53
5
FFFF
No step in
progress
83
85
Table of Contents
Default Chapter
2
Table of Contents
2
Safety Advisory / Warranty
4
Good Practices and Safety Instructions
4
Preamble
5
Introduction
5
Basic Notions
6
Hardware Installation
8
Hardware Configuration
8
Cabling
9
Configuration of the ATEQ Device (Slave)
10
Setup of the CC-Link Configuration Mode
10
Setup of the Station Address
12
Setup of the Communication Speed
13
Setup of the Output Mode
14
Configuration of the Master
15
Configure the MELSEC Board as Master
15
Describe the Slaves to the Master
17
Download the Configuration to the Master
19
Verification
20
Functional Description of an ATEQ Device
21
Introduction
21
Write Table and Read Mode
22
Configuration
51
Cycle
76
Results
81
SLMP Parameters
93
