Last results
Last results structure
At the end of each cycle, the last result is as an array of 40 words. This result includes the final state of
the instrument (relays position, alarm signal, indicators state…), but also of the test (units, values
measured for the pressure and the flow).
The last result is in the memory of the instrument. To obtain them, it is necessary to carry out a “Read
last results” request.
Standard results
The standard result structure contains 36 bytes.
Words
Meaning
*ERD Only
Type
Bytes
Coeff
1
Program number.
Word
2
2
Test type.
Word
2
3
Image of the relays:
Bit 0 = 1: pass part.
Bit 1 = 1: fail part, maximum flow reject.
Bit 2 = 1: fail part, minimum flow reject.
Bit 3 = 1: alarm.
Bit 4 = 1: unused.
Bit 5 = 1: reserved.
Bit 6 = 1: unused.
Bit 7 = 1: unused.
Word
2
4
Alarm code (refer to the alarm codes table).
Word
2
5
Pressure low part word.
Long
4
x1000
6
Pressure high part word.
7
Pressure unit code low part word (refer to units table).
Long
4
x1000
8
Pressure unit code high part word (refer to units table).
9
Flow low section word.
Long
4
x1000
10
Flow high section word.
11
Flow unit code low part word (refer to. Units table).
Long
4
x1000
12
Flow unit code high part word (refer to. Units table).
13
Step pressure low part word *
Long
4
x1000
14
Step pressure high part word *
15
Step pressure unit code low part word (refer to units table) *
Long
4
x1000
16
Step pressure unit code high part word (refer to units table) *
17
Step flow low part word *
Long
4
x1000
18
Step flow high part word *
