Configuration of the master
INSTALLATION OF THE PROFIBUS MODULE
Identification of the version of the Profibus module
You can identify the hardware configuration using your ATEQ device or using a fieldbus configuration
software.
For the installation and configuration of the Profibus module, you have to select the component that
corresponds to the firmware (see Configuration files).
From the ATEQ device
From the MAIN MENU screen of your
ATEQ device:
➢
SERVICE
➢
FIELDBUS
The Hilscher firmware version is
displayed in the FIRMWARE parameter.
From the ATEQ Fieldbus Configurator software
Connect your PC to the RS232 connector of your ATEQ device.
Run the ATEQ Fieldbus Configurator software:
The Hilscher firmware version is displayed in the FIRMWARE parameter.
