RESULTS
FIFO results
FIFO list results structure
At the end of each cycle, a result is stored as an array of 40 words contained in a FIFO of 8 results.
This result includes the final state of the instrument (relays position, alarm signal, indicators state…),
but also of the test (units, values measured for pressure and flow).
The results are in the memory of the instrument. To obtain them, it is necessary to carry out a “Read
FIFO results” request.
Words
Meaning
*ERD Only
Type
Bytes
Coeff
1
Program number.
Word
2
2
Test type.
Word
2
3
Image of the relays:
Bit 0 = 1: pass part.
Bit 1 = 1: fail part, maximum flow reject.
Bit 2 = 1: fail part, minimum flow reject.
Bit 3 = 1: alarm.
Bit 4 = 1: unused.
Bit 5 = 1: reserved.
Bit 6 = 1: unused.
Bit 7 = 1: unused.
Word
2
4
Alarm code (refer to the alarm codes table).
Word
2
5
Pressure low part word.
Long
4
x1000
6
Pressure high part word.
7
Pressure unit code low part word (refer to units table).
Long
4
x1000
8
Pressure unit code high part word (refer to units table).
9
Flow low section word.
Long
4
x1000
10
Flow high section word.
11
Flow unit code low part word (refer to. Units table).
Long
4
x1000
12
Flow unit code high part word (refer to. Units table).
13
Step pressure low part word *
Long
4
x1000
14
Step pressure high part word *
15
Step pressure unit code low part word (refer to units table) *
Long
4
x1000
16
Step pressure unit code high part word (refer to units table) *
17
Step flow low part word *
Long
4
x1000
18
Step flow high part word *
19
Step flow unit code low part word (refer to units table) *
Long
4
x1000
20
Step flow unit code high part word (refer to units table) *
21
Drop pressure low part word *
Long
4
x1000
22
Drop pressure high part word *
23
Drop pressure unit code low part word (refer to units table) *
Long
4
x1000
24
Drop pressure unit code high part word (refer to units table) *
25
Pa – Pa/s Leak result low part word
Long
4
x1000
26
Pa – Pa/s Leak result high part word
27
Drop flow unit code low part word (refer to units table) *
Long
4
x1000
28
Drop flow unit code high part word (refer to units table) *
