EN
23
1.2 - Mounting
The unit is mounted
on the wall using a set
of screws/plugs
(supplied).
2 - Activation
2.1 - Installing the batteries
Your device is powered by two 1.5 V LR3 /
LR03 - AAA type lithium batteries. See § 5.1
2.2 - Setting the time
See § 5.3
2.3 - Association
An ATERNO heater has a corresponding thermostat
(possible to control several heaters with the same thermostat).
The configuration mode is used to associate the heater(s)
with a thermostat (no conflict possible with neighbouring
installations). It is also used to check the wireless transmission.
➊ On the heater:
Press the button of the heater to be associated for 3 seconds
until the green “TH” LED flashes slowly, then release.
2705157_rev3_not_TAP_ATERNO_SMART 17/12/2019 12:32 Page 23
