15
16
3.8 Packaging information
No. Name
Unit
1
2
3
4
5
Inverter main unit
Wall-mounting accessory
Expansion bolt
user manual
certificate
pcs
set
set
pcs
pcs
Quantity
1
1
6
1
1
Table 3-8-1 Packaging information
Products installation 4
4.1 Installation condition requirements
To ensure normal operation of the machine, the installation environment is required
as follows:
A. The wall for mounting HPS should be solid and able to bear the weight of HPS in
the long term.
B. Installation space should be sufficient to cover HPS dimension, HPS dimension
and installation gap please see below photo:
C. Do not install HPS on flammable or heat vulnerable materials or buildings
D. Do not install HPS in a space without good ventilation or dusty, it will cause low
cooling fan efficiency, then reduce HPS efficiency, the fan and fan cover should be
checked and cleaned every 6 months
E. To avoid overheat and power derating, please do not expose HPS under the sun
F. Environment temperature around HPS should be -25î ~55î
G. HPS can be installed on vertical or tilted surface as shown in below figure:
H. Please ensure sufficient space
I. Do not install HPS beside TV antenna, mobile network devices or lightning rods to
ground.
J. Do Not install HPS in residential area
K. Do not install HPS in area within reach of children
