Atlantic Technology 222 PBM - Connection Examples; Subwoofer Line Out;Low Level In; Preamp Line Out;Low Level In

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
A TECHNOLOGY
tlantic
Models 222 PBM, 262 PBM and 352 PBM THX
8
L/MONO
HI LEVEL INPUTLOW LEVEL INPUT
R
L/MONO R
IN
THRU
IN
THRU
L/MONO
HI LEVEL INPUTLOW LEVEL INPUT
R
L/MONO R
IN
THRU
IN
THRU
Sub Woofer Out
Single Sub Woofer Optional Second Sub Woofer
Receiver/Amplifier
Example 1:
Subwoofer Line
Out/Low Level In
This is the most
commonly used
system connection
for systems with
Dolby Pro Logic
receivers.
Example 2:
Preamp Line
Out/Low Level In
for 1 Subwoofer
This arrangement
is for owners of
stereo receivers/
amplifiers with
Preamp outputs.
If your receiver/
amplifier uses
jumper links be-
tween the Pre-out
and Main In, then
you must remove
them and use
option 1 or 2. If
your receiver/
amplifier uses a
switch instead of
connectors, then
use option 3.
L/MONO
HI LEVEL INPUTLOW LEVEL INPUT
R
L/MONO R
IN
THRU
IN
THRU
Left Sub Woofer
Pre Out
Main In
LR
Receiver/Amplifier
L/MONO
HI LEVEL INPUTLOW LEVEL INPUT
R
L/MONO R
IN
THRU
IN
THRU
Pre Out
Main In
LR
L/MONO
HI LEVEL INPUTLOW LEVEL INPUT
R
L/MONO R
IN
THRU
IN
THRU
L/MONO
HI LEVEL INPUTLOW LEVEL INPUT
R
L/MONO R
IN
THRU
IN
THRU
Pre Out
Main In
LR
Internal
Pre Amp
External
Pre Out
Main In
LR
Y-adapters
Option 1
Option 2
Option 3
