Atlas Copco AWC160

Instruction Manual
LRP200000228 Issue A 9
2 Technical Data
2.1 Operating and storage conditions
Table 1 – Operating and storage conditions
Ambient operating temperature range
-20 °C to 50 °C
Ambient storage temperature range
-30 °C to 50 °C
Maximum ambient operating humidity
90 %
Maximum operating altitude
1000 m ASL
Maximum inlet gas temperature
80 °C
If you use a water-based sealing liquid, where ambient temperatures can fall close to 0 °C or below, take
appropriate precautions to ensure that the liquid does not freeze and damage the pump
2.2 Mechanical data
Table 2 – Mechanical data
Item
Reference data
Dimensions
Refer to GA drawing LRP20000A727
Mass
Refer to GA drawing LRP20000A727
Process, sealing liquid and seals flush connections
Refer to GA drawing LRP20000A727
Maximum flatness deviation for mounting
*
AWC160, AWC220, AWC290, AWC390
0.1 mm/m
* Refer to Section 3.7.
2.3 Performance
NOTE
The performance data specified in Table 3 to Table 6 applies to pumps used with water as the
sealing liquid. Additional performance data may be supplied in your System Manual if you have
specifically ordered your pump for use with a different sealing liquid.
The "Maximum sealing liquid flow rate" data specified in Table 6 may include seals flush liquid which
flows into the sealing liquid ring on pumps without a closed-loop seals configuration. Refer to your
System Manual for the specific details of your pump system.
