Atlas Copco DYNAPAC Svedala Demag DF 115 C - Type of Machine: PLC- Electronics; Switch Box

To Next Page

To Previous Page

F 8.1 16

F_8.1_01_GB.fm 16-20

Type of machine: PLC- electronics

Switch box

Main fuses (A)

A Main fuses

B Fuses in the switching cabinet

C Relays in the switching cabinet

F. A

3.1 Main fuses 50

3.2 Reserve 50

Fuses_635_konv.eps

B C
