13/08/2013 PM 9845 0187 01 Page 12 of 24
Modbus Parity
Below table lists the possible Modbus parities, indicated as follows:
Display value Parity
0 None
1 Even
2 Odd
Modbus Stopbits
Select the number of used stopbits (1 or 2).
Profibus Engine
The Profibus Engine can be started/stopped here.
NOTE: In case the Profibus Engine is active, the settings for Profibus SlaveAddress and Profibus DataRecords are not accessible.
Profibus SlaveAddress
The Profibus SlaveAddress can be adjusted here.
Display value
1 .. 255
Profibus DataRecords
There are 4 possible settings, indicated as follows:
Display value #
1 1 data record
2 2 data records
4 4 data records
8 8 data records
EtherNet Engine
The EtherNet Engine can be started/stopped here.
EtherNet IP Address
The EtherNet IP Address can be set/altered here.
EtherNet Network Mask
The EtherNet Network Mask can be set/altered here.
EtherNet Gateway
The EtherNet Gateway can be set/altered here.
