Atlas Copco G 22

Frequency
(Hz)
Voltage (V) G 15L G 18 G 22
CSA/UL Overload
relay FM1
(A)
FU Main
fuses
(A) (class J
or RK5) +
Disc.
Switch IG
size
>=1,25 x
FLA, see
conn.
Diagram.
Overload
relay FM1
(A)
FU Main
fuses
(A) (class J
or RK5) +
Disc.
Switch IG
size
>=1,25 x
FLA, see
conn.
Diagram.
Overload
relay FM1
(A)
FU Main
fuses
(A) (class J
or RK5) +
Disc.
Switch IG
size
>=1,25 x
FLA, see
conn.
Diagram.
60 200 41.2 80 49.6 100 58.6 110
60 230 36.6 80 44.2 100 51.7 110
60 460 18.3 45 22.1 50 25.9 60
60 575 14.5 40 17.5 50 20.6 50
Full Feature version
Frequency
(Hz)
Voltage (V) G 15L G 18 G 22
IEC Overload
relay FM1
(A)
Fuses FU
(aM/gG)
Overload
relay FM1
(A)
Fuses FU
(aM/gG)
Overload
relay FM1
(A)
Fuses FU
(aM/gG)
50 230 36.0 80A / 80A 43.5 100A /
100A
50.4 100A /
125A
50 400 20.6 50A / 50A 25.2 50A / 63A 29.0 63A / 80A
60 380 21.7 40A / 50A 25.9 50A / 63A 30.5 63A / 80A
60 460 18.3 40A / 40A 22.1 40A / 50A 25.9 50A / 63A
CSA/UL Overload
relay FM1
(A)
FU Main
fuses
(A) (class J
or RK5) +
Disc.
Switch IG
size
>=1,25 x
FLA, see
conn.
Diagram.
Overload
relay FM1
(A)
FU Main
fuses
(A) (class J
or RK5) +
Disc.
Switch IG
size
>=1,25 x
FLA, see
conn.
Diagram.
Overload
relay FM1
(A)
FU Main
fuses
(A) (class J
or RK5) +
Disc.
Switch IG
size
>=1,25 x
FLA, see
conn.
Diagram.
60 200 41.2 100 49.6 125 58.6 150
60 230 36.6 100 44.2 125 51.7 150
60 460 18.3 50 22.1 60 25.9 70
60 575 14.5 40 17.5 50 20.6 60
Instruction book
2920 7119 21 79
