Atlas Copco G 22

Control panel
Control panel G 15L, G18 and G 22
Reference Designation
1 Electric cabinet
ER Elektronikon™ Base controller
S3 Emergency stop button
DMS Dryer Main Switch (Only on Full-Feature units)
2.7 Electrical system
Electrical components
The electrical system comprises the following components:
Electric cubicle IEC
Instruction book
