11.5 Settings of circuit breakers
IEC
Network
system
Supply
voltage
(V)
Frequency(
Hz)
Approval
Q1 (A)
STD
Q1 (A)
HAT
Q20
(A)
STD
Q20
(A)
HAT
Q2
(A)
Q40
(A)
Q41
(A)
TT/TN 380 50 IEC 2.3 2.3 28 31 59 20 9
TT/TN 400 50 IEC 2.22 2.22 28 31 59 - 9
TT/TN 500 50 IEC 1.78 1.78 20 25 48 20 9
TT/TN 380 60 IEC 2.3 2.3 28 31 59 - 9
TT/TN 440 60 IEC 2.02 2.02 28 31 59 20 9
IT 380 50 IEC 2.3 2.3 28 31 59 20 9
IT 400 50 IEC 2.22 2.22 28 31 59 - 9
IT 500 50 IEC 1.78 1.78 20 25 48 20 9
IT 380 60 IEC 2.3 2.3 28 31 59 - 9
IT 440 60 IEC 2.02 2.02 28 31 59 20 9
CSA/UL
Network
system
Supply
voltage
(V)
Frequency
(Hz)
Approval
Q1 (A)
STD
Q1 (A)
HAT
Q20
(A)
STD
Q20
(A)
HAT
Q2
(A)
Q40
(A)
Q41
(A)
TT/TN 460 60 CSA/UL 2.5 2.5 28 31 59 - 9
TT/TN 575 60 CSA/UL 2.5 2.5 17 17 36 20 9
IT 460 60 CSA/UL 2.,5 2.5 28 31 59 - 9
IT 575 60 CSA/UL 2.5 2.5 17 17 36 20 9
11.6 Compressor data
Data for GA 8.5 bar (123.3 psi) 50 Hz compressors
Units GA 110 VSD GA 132 VSD GA 160 VSD
Maximum working pressure, GA Pack bar(e) 8.5 8.5 8.5
Maximum working pressure, GA Pack psig 123 123 123
Maximum working pressure, GA Full-
Feature
bar(e) 8.3 8.3 8.3
Maximum working pressure, GA Full-
Feature
psig 120 120 120
Instruction book
150 2920 1728 05
