Atlas Copco GA 37+ - Page 142

142
Instruction book
9096 3321 00
Units 7.5 bar 8 bar 10 bar 13 bar
Reference working
pressure, units
without dryer
bar(e) 7 8 9.5 12.5
Reference working
pressure,
Workplace Full-
Feature units
bar(e) 7 7.75 9.5 12.5
Pressure drop over
dryer, Full-Feature
units
bar(e) 0.23 0.23 0.14 0.08
Set point,thermostatic
valve
40 40 40 65
Temperature of air leaving
outlet valve (approx),air-
cooled units without dryer
30 30 30 30
Temperature of air leaving
outlet valve (approx),water-
cooled units without dryer
32 32 32 32
Temperature of air leaving
outlet valve (approx.),Full-
Feature units
25 25 25 25
Pressure dewpoint,Full-
Feature units
4 4 4 4
Drive motor,
SIEMENS
1LG6
228-2
1LG9
228-2
1LG9
228-2
1LG9
228-2
Motor shaft speed r/min 2965 2965 2965 2965
Nominal motor
rating
kW 75 75 75 75
Power consumpation
Dryer at full load,
Full-Feature units
kW 2.7 2.7 2.7 2.7
0
C
0
C
0
C
0
C
0
C
