Atlas Copco ga75+ - Page 142

142
Instruction book
9096 3313 00
Digital outputs
Digital inputs
Analog inputs
Parameter Value
Number of outputs 9 (Elektronikon® Graphic controller-p.n. 1900 5200
10..... 1900 5200 19)
Type Relay (voltage free contacts)
Rated voltage AC 250 V AC /10 A max.
Rated voltage DC 30 V DC /10 A max.
Parameter Value
Number of inputs 10 (Elektronikon® Graphic controller- p.n. 1900
5200 10 .... 1900 5200 19)
Supply by controller 24 VDC
Supply protection Short circuit protected to ground
Input protection Not isolated
Parameter Value
Pressure inputs 2 (Elektronikon® Graphic controller-p.n. 1900 520010 .... 1900
5200 19)
Temperature inputs
5 (Elektronikon® Graphic controller-p.n. 1900 520010 .... 1900
5200 19)
