2920 1381 02
18
Instruction book
2.3 Electric cable size 1)
2.3.1 For GA55/GA55 W 2) 3)
Supply Frequency - LC cable MC cable LC cable MC cable
voltage Approval GA Pack GA Pack GA Full-feature GA Full-feature
(V) (mm²/AWG) (mm²/AWG) (mm²/AWG) (mm²/AWG)
230 50 - IEC 2 x 35 2 x 50 2 x 50 2 x 50
400 50 - IEC 50 70 50 70
500 50 - IEC 35 50 35 50
220-230 60 - IEC 2x 35 2x 50 2x 50 2x 50
220-230 60 - CSA/UL 2x AWG3 2x AWG0 2x AWG2 2x AWG00
380 60 - IEC 50 70 70 70
380 60 - CSA/UL AWG2 AWG00 AWG1 AWG000
440-460 60 - IEC 35 50 50 50
440-460 60 - CSA/UL AWG3 AWG0 AWG2 AWG00
575 60 - IEC 25 35 35 35
575 60 - CSA/UL AWG4 AWG2 AWG4 AWG1
2.3.2 For GA75/GA75 W 2) 3)
Supply Frequency - LC cable MC cable LC cable MC cable
voltage Approval GA Pack GA Pack GA Full-feature GA Full-feature
(V) (mm²/AWG) (mm²/AWG) (mm²/AWG) (mm²/AWG)
230 50 - IEC 2x 70 2x 70 2x 70 2x 70
400 50 - IEC 2x 25 2x 35 2x 25 2x 35
500 50 - IEC 50 70 50 70
220-230 60 - IEC 2x 70 2x 70 2x 70 2x 95
220-230 60 - CSA/UL 2x AWG1 2x AWG000 2x AWG0 2x AWG0000
380 60 - IEC 2x 25 2x 35 2x 25 2x 35
380 60 - CSA/UL 2x AWG4 2x AWG2 2x AWG4 2x AWG1
440-460 60 - IEC 2x 25 2x 25 2x 25 2x 25
440-460 60 - CSA/UL 2x AWG4 2x AWG3 2x AWG4 2x AWG2
575 60 - IEC 50 50 50 50
575 60 - CSA/UL AWG2 AWG00 AWG4 AWG1
2.3.3 For GA90C/GA90C W 2) 3)
Supply Frequency - LC cable MC cable LC cable MC cable
voltage Approval GA Pack GA Pack GA Full-feature GA Full-feature
(V) (mm²/AWG) (mm²/AWG) (mm²/AWG) (mm²/AWG)
230 50 - IEC 2x 70 2x 95 2x 70 2x 95
400 50 - IEC 2x 35 2x 35 2x 35 2x 35
500 50 - IEC 70 70 70 95
