2920 1381 02
6
Instruction book
Daa Automatic condensate drain outlet
Dma Manual condensate drain valve
1 Pictograph, automatic condensate drain outlet
2 Pictograph, manual condensate drain valve
Fig. 1.5 Condensate drains
AF Air filter
AR Air receiver
BV Oil cooler by-pass valve
Ca Air cooler
DP1 Oil drain plug, air receiver
FC Oil filler plug
FN Fan
Gl Oil level gauge
M2 Fan motor
OS Oil separator element
Vp Minimum pressure valve
1 Dryer
2 Air inlet pipe
Fig. 1.4 Rear view of GA75 Full-feature
FN M21
Ca
DP1
Vp
2
BV
OS
AR
G
L
FCAF
50346F
Daa
50513F
Dma
1
2
