- 56 -
COMPRESSOR/ENGINE/GENERATOR SPECIFICATIONS
REFERENCE CONDITIONS
The inlet conditions are specified at the air inlet grating outside the canopy.
Designation XA(S) 137 DD -
XA(S) 300 DD7
XA(S) 137 DDG -
XA(S) 300 DD7G
XAHS 107 DD -
XAHS 250 DD7
230/400 V (3 phase)
Absolute inlet pressure bar(e) 1 1 1
psi 14.5 14.5 14.5
Relative air humidity % 0 0 0
Air inlet temperature °C 20 20 20
°F 68 68 68
Nominal effective working pressure bar(e) 7 7 12
psi 102 102 174
