Atlas Copco XA(S) 300 DD7

- 58 -
Performance data
Max. allowable working pressure as a function of altitude and ambient temperature.
6000
5000
4000
3000
2000
1000
0
14 32 50 68 86 104 122
-10,0 0,0 10,0 20,0 30,0 40,0 50,0
16.405
13.124
9.843
6.562
3.281
0 ft
07 bar(e)
102 psi
27/jul/07
XAS 137 Dd
XAS 300 DD7
ALTITUDE IN M
ALTITUDE IN FT
TEMPERATURE IN °F
TEMPERATURE IN °C
6000
5000
4000
3000
2000
1000
0
14 32 50 68 86 104 122
-10,0 0,0 10,0 20,0 30,0 40,0 50,0
16.405
13.124
9.843
6.562
3.281
0 ft
07 bar(e)
3/aug/07
XAS 137 DdG
XAS 300 DD7G
102 psi
ALTITUDE IN M
ALTITUDE IN FT
TEMPERATURE IN °F
TEMPERATURE IN °C
6000
5000
4000
3000
2000
1000
0
14 32 50 68 86 104 122
-10,0 0,0 10,0 20,0 30,0 40,0 50,0
16.405
13.124
9.843
6.562
3.281
0 ft
12 bar(e)
174 psi
27/jul/07
XAHS 107 Dd
XAHS 250 DD7
ALTITUDE IN M
ALTITUDE IN FT
TEMPERATURE IN °F
TEMPERATURE IN °C
